Evaluation Board for the
FEATURES
Full featured evaluation board for the
Compatible with the
AD5673R
Various link options
PC control in conjunction with the Analog Devices, Inc.,
board
EVALUATION KIT CONTENTS
EVAL-AD5677RSDZ
HARDWARE REQUIRED
EVAL-SDP-CB1Z
(SDP-B) board, must be purchased separately
SOFTWARE REQUIRED
Analysis | Control | Evaluation
download from the EVAL-AD5679RSDZ product page
GENERAL DESCRIPTION
This user guide describes the operation of the EVAL-
AD5677RSDZ for the
AD5677R
output, digital-to-analog converter (DAC). The EVAL-
AD5677RSDZ is also compatible with the AD5673R.
The EVAL-AD5677RSDZ allows users to quickly prototype
AD5673R/AD5677R
circuits and reduce design time. The
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
AD5677R
AD5677R
SDP-B
software, available for
16-bit, 16-channel, voltage
EVALUATION BOARD PHOTOGRAPH
EVAL-AD5677RSDZ
16-Bit, 16-Channel, Voltage Output DAC
AD5673R/AD5677R
supply range. The
2.5 V reference to provide an output voltage of 2.5 V or 5 V.
The EVAL-AD5677RSDZ also incorporates an additional
on-board voltage reference.
The EVAL-AD5677RSDZ interfaces to the USB port of a PC
via a system demonstration platform (SDP-B) board. The
Analysis | Control | Evaluation (ACE) software is available for
download from the EVAL-AD5677RSDZ product page. Use
this software with the evaluation board to program the
AD5673R/AD5677R. A peripheral module interface (PMOD)
connection is also available to allow the connection of
microcontrollers to the evaluation board without the
board. When a microcontroller is used through the PMOD
connection, the
user is unable to operate the
The EVAL-AD5677RSDZ is compatible with any Analog
Devices
SDP-B
typical connection between the EVAL-AD5677RSDZ and the
SDP-B
controller board is shown in Figure 1.
For full details, see the
must be used in conjunction with this user guide when using
the EVAL-AD5677RSDZ.
Figure 1.
Rev. 0 | Page 1 of 13
User Guide
operates from a single 2.7 V to 5.5 V
AD5673R/AD5677R
incorporates an internal
SDP-B
board must be disconnected, and the
ACE
software.
board, which can be purchased separately. A
AD5673R/AD5677R
UG-1766
SDP-B
data sheet, which
