Removal of Air Filters

1. Removal of Air Filters
Procedure
Step
1. Appearance feature
2. Remove the air filter.
Open the front panel to
1
the position where it
stops.
2 Slightly push up the
center knob of the air
filter and unfasten the
hooks.
Pull out the air filter
3
downward and remove
it.
2
Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Procedure
Signal receiver
[ON/OFF] button Room temperature
thermistor
Front panel
Air filter
Dangerous: High voltage
A high voltage is applied to
all the electric circuits of this
product including
thermistors.
When the signal receiver
catches a signal from the
remote controller, the
receiving tone sounds and
(R4305)
the operation lamp blinks
immediately to confirm the
Operation lamp
TIMER lamp
signal reception.
INTELLIGENT EYE
When the [ON/OFF] button
lamp
is kept pressed for 5
seconds, the forced cooling
operation is performed for
about 15 minutes.
INTELLIGENT EYE
sensor
(R4306)
(R4307)
The air filter is not marked
for difference between the
right and left sides.
Insert the air filter with the
"FRONT" mark faced up.
The air filter can be set
easily by inserting it along
the guides.
Be sure to insert the hooks
(at 2 lower positions) when
reassembling the air filter.
(R4308)
Si04-751
Points
Warning
Removal Procedure
