- Page 1 User reference guide Daikin room air conditioner ATXM20N2V1B ATXM25N2V1B User reference guide ATXM35N2V1B English Daikin room air conditioner ATXM50N2V1B...
-
Page 2: Table Of Contents
Wireless LAN connection ............13 DANGER: RISK OF EXPLOSION 5.12.1 Precautions when using the wireless adapter..... 13 5.12.2 To install the Daikin Online Controller application ..13 Indicates a situation that could result in explosion. 5.12.3 Wireless adapter components ........13 5.13 About Multi system .............. -
Page 3: For The User
Latest revisions of the supplied documentation may be available on ▪ Do NOT sit, climb or stand on the unit. the regional Daikin website or via your installer. ▪ Units are marked with the following symbol: The original documentation is written in English. All other languages are translations. -
Page 4: About The System
NOT blocked by curtains or other objects. NOTICE ▪ Do NOT drop the user interface. ▪ Do NOT let the user interface get wet. Air inlet Air outlet User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 5: Components: User Interface
Beep-beep Operation starts. Beep Setting changes. Operation mode = Fan only Long beep Operation stops. Powerful operation is active Econo operation is active Outdoor unit quiet operation is active ATXM20~50N2V1B User reference guide Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 6: Before Operation
Result: Brightness will be changed in order: high, low, off. 3 Hang the user interface on the user interface holder. To turn on the power supply 1 Turn the circuit breaker on. User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 7: Operation
During defrosting operation, hot air is NOT viruses, bacteria… blown from the indoor unit. ATXM20~50N2V1B User reference guide Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 8: To Start/Stop Operation And To Set The Temperature
Efficiency will drop if a wall blocks the air. Airflow direction 5.5.3 To use 3-D airflow direction When. Adjust the airflow direction as desired. 1 Press User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 9: Comfort Airflow And Intelligent Eye Operation
▪ The temperature can be set Vertical angle (side view) Horizontal angle (top view) only in Automatic mode. Drying ▪ The temperature setting is lowered by 2.5°C. ▪ The airflow rate is slightly increased. ATXM20~50N2V1B User reference guide Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 10: Econo And Outdoor Unit Quiet Operation
Note: Econo operation can be only set when the unit is running. 4 To stop operation, press Pressing cancels the setting and disappears from the LCD. User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 11: To Start/Stop On Timer Operation
With this operation, you can save up to 4 timer settings for each day of the week. Example: Create a different setting from Monday to Friday and a Display Feature different setting for weekends. ON timer OFF timer Blank Deletes reservation ATXM20~50N2V1B User reference guide Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 12: To Copy Reservations
Result: The selected reservation is deleted. 6 Press to exit. 5 Press Result: Remaining reservations will be active. Result: The whole reservation is copied to the selected day and the timer lamp lights orange. User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 13: Wireless Lan Connection
▪ Android 4.0.3 or later ▪ iOS 7.1.2 or later ▪ Internet line and communication device, such as a modem, router, etc. ▪ Wireless LAN access point ▪ Installed free Daikin Online Controller application 5.13.1 Priority room setting 5.12.1 Precautions when using the wireless Priority room setting requires initial programming during installation. -
Page 14: Night Quiet Mode
CAUTION Maintenance and service NEVER expose little children, plants or animals directly to the airflow. Overview: Maintenance and service The installer has to perform a yearly maintenance. User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 15: To Clean The Indoor Unit And User Interface
▪ Do NOT place any objects containing water on the unit. CAUTION Front panel shaft After a long use, check the unit stand and fitting for damage. If damaged, the unit may fall and result in injury. ATXM20~50N2V1B User reference guide Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 16: About The Air Filters
INFORMATION Replace the filter every 3 years. 1 Remove the filter from the tabs (class 20~35) or frame (class 50) and replace the filter with a new one. User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 17: To Re-Install The Front Panel
Stop operation and shut off the power if anything unusual occurs (burning smells etc.). Leaving the unit running under such circumstances may cause breakage, electric shock or fire. Contact your dealer. ATXM20~50N2V1B User reference guide Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 18: Symptoms That Are Not System Malfunctions
Other electric If the user interface signals operate other system protection. appliances start to electric appliances, move the other operate. appliances away, and contact your dealer. User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 19: Solving Problems Based On Error Codes
High-pressure control (in cooling mode) Wireless adapter Compressor system sensor abnormality operating. Repeat Position sensor abnormality necessary. DC voltage / current sensor abnormality ATXM20~50N2V1B User reference guide Daikin room air conditioner 4P518786-2C – 2018.09... -
Page 20: Solving Problems Based On The Led On The Outdoor Unit
Technical skilled person who is qualified to install the parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for product. reuse, recycling and recovery. User reference guide ATXM20~50N2V1B Daikin room air conditioner 4P518786-2C – 2018.09... - Page 21 Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with product according instructions accompanying documentation.
