Removal of Horizontal Blades / Vertical Blades
Step
2. Remove the horizontal
blade (small).
1 Unfasten the center
shaft while bending the
horizontal blade (small)
slightly.
2 Unfasten the left shaft.
Unfasten the right shaft.
3
8
Procedure
Horizontal blade (small)
(R4332)
(R12716)
Key alignment
There is a key alignment at
the right shaft. When
reassembling, insert the
right shaft first while turning.
After inserting the right
shaft, mount the horizontal
blade to the center shaft and
then to the left shaft.
(R4334)
Si04-751
Points
Removal Procedure
