Si04-751
Step
7. Remove the display PCB.
The figure shows the
1
connection of wire
harness for the display
PCB.
2
Unfasten the 3 hooks
and remove the display
PCB.
Disconnect the
3
connector [S27] from
the display PCB.
8. Remove the control PCB.
Unfasten the 2 lower
1
hooks.
Removal Procedure
Procedure
Hook
[S27]
Green
LED 1
Control
PCB
Hook
Display PCB
(R4366)
(R4367)
Green
Yellow
LED 3
LED 2
(R4368)
Hook
(R4369)
Removal of PCBs
Points
The display PCB is located
at the back of the signal
receiver unit.
17
