Removal of PCBs
Step
6. Remove the
INTELLIGENT EYE
sensor PCB.
Remove the
1
INTELLIGENT EYE
fixing plate by twisting
it.
Unfasten the right 3
2
hooks and remove the
INTELLIGENT EYE
sensor PCB.
There are also 2 hooks
on the left side.
Disconnect the
3
connector [S36] from
the INTELLIGENT EYE
sensor PCB.
16
Procedure
INTELLIGENT EYE
sensor PCB
Some models have no
INTELLIGENT EYE sensor
PCB.
INTELLIGENT EYE
fixing plate
(R4363)
(R4364)
[S36]
(R4365)
Si04-751
Points
Removal Procedure
