- Page 1 Manuale di installazione Installation manual uso e manutenzione Electric pre/post heating Modular T Smart ATB Modular T D-EIMOC2009-22_00EN Modular T Modular T Smart ABT DATE October 2022 Original translations Traduzione delle istruzioni originali REPLACES...
-
Page 2: Important Warnings
Important warnings The pictogram shows a situation of immediate danger or a dangerous situation that might cause injuries or death. The pictogram shows that it is necessary to adopt suitable behaviour in order to avoid jeopardising staff safety and cause damages to the equipment. The pictogram shows particularly important technical information that should be taken into consideration by the people installing or using the equipment. -
Page 3: Technical Data
Technical data Modular T PRO Load Weight Supply Size Material name voltage ATD03HEFAU 3-phase; 400V ATD03HESAU 3-phase; 400V ATD04HEFAU 15.4 3-phase; 400V ATD04HESAU 3-phase; 400V ATD05HEFAU 17.4 3-phase; 400V ATD05HESAU 3-phase; 400V ATD06HEFAU 22.3 3-phase; 400V ATD06HESAU 10.5 3-phase; 400V ATD07HEFAU 29.4... - Page 4 MODULAR T MODULAR T SMART POST HEATING HEATING HEATING Probe Probe Suggested distance Suggested beetween distance probe and coil beetween Electric coil probe and coil Electric coil Suggested distance Electric coil beetween Suggested probe and coil distance Suggested beetween coil...
-
Page 5: Installation
Installation MODULAR T supporting brackets (not supplied) air ducts (not supplied) HEATING HEATING supporting brackets (not supplied) POST POST HEATING HEATING Right Handling Left handling VERSION MACHINES VERSION MACHINES ATB**R** ATB**L** DUCT Exhaust air Fresh air Return air Supply air... - Page 6 MODULAR T SMART supporting brackets (not supplied) air ducts (not supplied) HEATING HEATING Right Handling Left handling VERSION MACHINES VERSION MACHINES ATB**R** ATB**L** DUCT Exhaust air Fresh air Return air Supply air Machine duct, example...
- Page 7 Electric post/pre heating coil can be positioned horizontally and vertically. both The ducts and the electric coils must be permanently fixed to a fixed structure (for example a wall or a ceiling) using brackets (not supplied). Electric post/pre heating coil should be installed in such a way that it is accessible for maintenance or any other operation.
-
Page 8: Electrical Connections
Electrical connections Power supply L2 L3 Power supply of electric pre/post heating... - Page 9 Modular T Smart version only Connection of PRE-HEATING probe Electric pre/post heating coil Suggested distance beetween probe and coil Pre-heating probe Connect the probe according to the supplied wiring diagram ø5mm ø10mm ø5mm provided Installation of probe (PRE-HEATING)
- Page 10 SET POINT Potentiometer TEMPERATURE set the target temperature °C Reset button the electric coils have 3 safety thermostats that intervene in case of high temperature; the thermostats (B) are set at 50 °C and are self-resetting, while the thermostat (A) is set at 100 °C and must be manually reset by pushing the reset button The electric coil has an alarm contact that...
- Page 11 Modular T Pro version only PRE-HEATING POST-HEATING PROBE PROBE Connection of probe (PRE/POST-HEATING)
- Page 12 Connection of PRE-HEATING probe ø10mm ALP00TEA Provided Provided Probe Suggested distance beetween probe and coil provided Electric coil Installation of probe (PRE-HEATING)
- Page 13 Connection of POST-HEATING probe ø10mm ALP00TEA Provided Provided Probe Suggested distance provided beetween probe and coil Electric coil Installation of probe (POST-HEATING)
- Page 14 P R E - H E A T I P O S T - H E A T I N G PRE-HEATING POST-HEATING Connection of alarm and signal cables...
- Page 15 Software setup (PRE HEATING) psw:2526...
- Page 16 Software setup (POST HEATING) psw:2526...
- Page 18 La presente pubblicazione è redatta solo come supporto tecnico e non costituisce impegno vincolante per Daikin Applied Europe S.p.A. Daikin Applied Europe S.p.A. ne ha compilato il contenuto al meglio delle proprie conoscenze. Nessuna esplicita o implicita garanzia è data per la completezza, precisione, affidabilità...
