MoveAxis Group – automatic travel to position:
Pos (mm or inch)
Speed [%]
Acc [%]
Start
Autotuning –automatic:
Rigidity
Start
Jog – manual operation:
Feedrate [%]
Monitor – axis state preview:
On position
Actual error
Max error
Axis position
C S - L a b s . c . – C S M I O / I P - A - C N C c o n t r o l l e r
Set motion position
Motion speed as % of maximal axis speed
Motion acceleration as % of maximal axis acceleration
Move to set position mode
Move to set position and back to initial position mode
Constant motion mode: to set position, to initial position, to
set position ... etc
Start to move
Setting target rigidity. By default 50%.
Autotuning mode start
Motion speed setting
Move towards -
Move towards +
A diode informs that axis does not make any move and is in
set position.
Actual deviation value from a set position
(encoder pulses number)
Maximal temporary error that occurred
(encoder pulses number)
Actual axis position (mm or inch)
