Signals on a Terminal Block connector

Axes by default are assigned to following channels:
XCh0 / YCh1 / etc.
Pin numbers Entered in Mach3 program in
Port&Pins" on „Motor Outputs" tab do not matter.
If you want to assign other STEP/DIR channels
numbers to an axis you should do it in the plugin's
configuration: menu „ConfigConfig
PlugInsCONFIG".
