10.9.6.4 Extras
In CSMIO/IP software few additional functions were implemented, which increase safety and comfort of
work.
Auto Z-InhEnable
Smart Limits
Probe protection
LegacyHomeOffset
10.9.6.5 CSMIO Connection Properties – additional connection options
Default MAC
Connected MAC
Name
ClearDefault
Set as Default
ChangeName
C S - L a b s . c . – C S M I O / I P - A - C N C c o n t r o l l e r
Automatic Z axis move limitation. Enables protection against
worktable of a machine damage. More details in chapter 14.1 –
Automatic Tool Length Measurement.
Movement blocking when hardware limit signal is active. It
works the way that e.g. when X++ signal is active, then we can
move X axis only in „-„ direction.
Tool length sensor protection. When Probe signal is active then
Z axis manual jog in „-„ (down) direction is blocked.
If Probe signal goes active during treatment, a machine will be
stopped just like in situation when E-Stop is pressed on.
Selecting this function cause Home Offset action change. A
machine after homing instead of travel back off with demanded
distance it will only enter the demanded distance into ma-
chine's coordinate.
Default MAC address for a connection. It's useful if in our local
network there are few CSMIO/IP controllers and we do not want
to select a controller we want to connect with at every Mach3
start. It is set by „Set as Default" button and reset using „Clear
Default".
Information about MAC address of currently connected
CSMIO/IP controller.
Currently connected controller name. You can name it by your-
self. The name will also be displayed in controller's selection
window if in local network there is more than one CSMIO/IP
controller. To give your name you must enter it and click
„Change Name".
Default MAC address deletion.
Default MAC address setting.
Private name setting for connected CSMIO/IP controller. It can
be any name. However it can't contain spaces or special char-
acters - e.g. „Lathe01".
