4.11 Recommended cables

Connections type
Digital In/out
Analog In/out
Encoder signals
Drives control
– analog signals +/-10V
Ethernet communication wire
Power supply
CAN expansion modules
During mechanical and electrical montage – particular caution is advised. Poorly tightened cable
may cause many troubles, it is also very difficult to find such a defect during launching/using the
system.
C S - L a b s . c . – C S M I O / I P - A - C N C c o n t r o l l e r
Recommended cable
Minimum cross-section 0,25mm
2
Cross-section 0,25mm (AWG-23)- shielded or pair of signal-to-
mass wires twisted together along the entire length
2
Cross-section 0,25mm (AWG-23) - shielded - twisted. Eventual-
ly PC FTP cable. You should remember that for pair of signals
(e.g. A+/A-) always use twisted pair of cables.
2
Cross-section 0,25mm (AWG-23) - shielded - twisted. Eventual-
ly PC FTP cable. You should remember that for pair of signals
(e.g. Out Analog Ch0 /GND Ch0) always use twisted pair of ca-
bles.
Standard network cable, shielded - FTP, cat. 6.
2
Min. cross-over 0,5mm (AWG-20)
If modules are installed on the same DIN rail, right next to the
controller, you can use DB9 plugs clamped on a 9 wire tape. If
module is installed farther then you should use so-called
shielded twisted pair. (FTP or STP).
2
(AWG-23)
