4.10 Recommended cables

Connections type
Digital In/out
Analog In/out
Drives control (STEP/DIR)
CSMIO/IP-S v1
Drives control (STEP/DIR)
CSMIO/IP-S v2
Ethernet Communication wire
Power
CAN expansion modules
During mechanical and electrical montage – particular caution is advised. Poorly tightened
cable may cause many troubles, it is also very difficult to find such a defect during
launching/using the system.
C S - L a b s . c . – C S M I O / I P - S - C N C C o n t r o l l e r
Recommended cable
Minimum cross-section 0,25mm
2
Cross-section 0,25mm (AWG-23)- shielded or pair of signal-
to-mass wires twisted together along the entire length
2
Cross-section 0,25mm (AWG-23)- shielded or pair of signal-
to-mass weirs twisted together along the entire length
2
Cross-section 0,25mm (AWG-23) - shielded–twisted. You
can possibly use the FTP computer cable. Please note that
pairs of signals (e.g., STEP + / STEP-) you should always lead
by twisted pair of cables.
Standard Power cable, shielded - FTP, cat. 6.
Min. Cross-section 0,5mm
If modules are installed on the same DIN rail, right next to
the controller, you can use DB9 plugs clamped on a 9-wire
tape. If module is installed farther then you should use so
call shielded twisted pair. (FTP or STP).
2
(AWG-23)
2
(AWG-23)
