Specifications

Port Configuration
Total Ports
16
Hardware Performance
Forwarding
Switching Capacity
Capacity
50.592 Mpps
Environmental Range
Operating Temperature
Fahrenheit Centigrade
‐4° to +140° ‐20° to+ 60°
Dimensions, Weights, Humidity
Dimensions (WxHxD)
Millimeter
280 x 44 x 134
Voltage and Frequency
Model Name
SM12DP2XA
Certifications
Electromagnetic Emissions (EMC)
FCC Class A, CE Safety: UL Listed
MTBF
Model
SM12DP2XA
SM12DP2XA
33751 Rev. C
SFP (100M/1G)
12
68 Gbps
Storage Temperature
Fahrenheit
‐4° to +158°
Inches
11 x 1.73 x 5.28
AC Input Voltage
100‐240 VAC, 50‐60 Hz
MTBF
270, 787 Hrs. GB, GC ‐ Ground Benign, Controlled. Temp: 25.00 deg. C.
58,838 Hrs. GB, GC ‐ Ground Benign, Controlled. Temp: 75.00 deg. C.
https://www.transition.com
Uplinks (100M/1G/10G)
2 SFP+ (1G/10G)
2 RJ45 (100M/1G)
Backplane Mac Table
68 Gbps
Centigrade
‐20° to +70°
Weight
Kilograms
1.0
DC Input Voltage
24‐48 VDC
SM12DP2XA Install Guide
Console
Jumbo Frames
32756 10200 Bytes
Altitude
Feet
< 10000
Operating Humidity
Pounds
10% to 90%
2.2
non‐condensing
Power Consumption
24 Watts (max)
Environment
RJ45
Meters
< 3000
