Specifications

11 Specifications

11.1 Nameplate

Check the nameplate and compare it with the order data.
Use the part number for reference.
The part number uniquely identifies the encoder box.
ISD Encoder Box
1
Encoder Box:
2
Uin: 24VDC
3
Iin/max: 0,5ADC
4
CAN Bus: 5VDC
5
Ambient: 5...40 C/41...104 F
6
Enclosure: IP 20
PART NO:
Illustration 11.1 Nameplate
The following data is shown on the nameplate of the ISD
encoder box:
11 11
1 Supply voltage
2 Current details
3 Bus details
4 Ambient temperature range
Table 11.1 Legend to Illustration 11.1
Ensure that the nameplate is clearly legible.

11.2 Storage

Store the encoder box in a dry, dust-free location with low
vibration (V
eff
The storage location must be free from corrosive gases.
Avoid sudden temperature changes.
30
o o o o
175G7750 SERIAL NO : 000000M000
175G775000000M000
Made in Germany
5
6
7
≤0.2 mm/s).
MG75F102 - VLT
®
VLT ISD Encoder Box Operating Instructions

11.3 Characteristic Data

Definition
Environmental Conditions
Operating temperature 5–40 °C
Storage temperature
Humidity
Protection rating
Vibration rating
Protection type
Housing
Dimensions (W x H x D) 142 x 105.2 x 70.78 mm
Weight
7
Mounting
Table 11.2 Characteristic Data
Protection rating
Part number
Serial number
®
is a registered Danfoss trademark
Value and Unit
0–55 °C
5–85%, non-condensing (according to
IEC 60721-3-3)
2
3M4
IP20
0.46 kg
In a control cabinet
