Installation/Fitting

5.6.5 Inserting the SD Card

NOTE
The SD card delivered with the encoder box is pre-
formatted and contains the necessary parameter file. If the
SD card has to be replaced, the new SD card must be
formatted and the parameter file copied to it before use.
See chapter4.3.3.5 SD Card Slot for further information
about formatting the SD card.
1. Insert the SD card into the slot above the display.

5.6.6 Connecting the 24 V Power Supply

1. Assemble the power supply cable according to
the connector pin assignment in chapter
4.3.3 Connections.
2. Connect the power supply as described in the
manual for the power supply.
®
