Operation VLT ISD Encoder Box Operating Instructions
7.1.4 <SET> Push Button
The <SET> push button can be used to scroll through the
list of messages and during the ID setting procedure.
The CAN-ID is shown when the push button is pressed for
3 seconds.
7.1.5 <CAN-ID> BCD Switch
The <CAN-ID> BCD switch is used to assign the ID
manually. See chapter 6.2.4 CAN-ID Setting.

7.1.6 Service Interface

CAUTION
The service interface is only for use by Danfoss Service.
7 7

7.2 Display via Toolbox and CoDeSys

In addition to the display on the ISD encoder box, it is
possible to query the status of the encoder box via ISD
Toolbox.
In order to do this, it is necessary to connect to the CAN
bus network via a PC/laptop. A CAN dongle is required,
which realises the physical connection between the CAN
bus network and the encoder box.
The ISD Toolbox enables the individual ISD components to
be displayed directly and thereby information about the
ISD components to be attained.
The parameters of the ISD components can also be read
via CoDeSys on the master controller.
The ISD Toolbox software, firmware updates, EDS files and
CoDeSys libraries can be downloaded from the Danfoss
website (www.danfoss.com).
®
