1.3. IDR

The IDR is an encased CPE indoor radio module available with an integral antenna or with a TNC-type port for
attaching a third-party antenna. The IDR provides a removable front cover for access to port interfaces.
Chassis cover bolt
RJ-45 10Base-T port
For IDR antenna alignment, the IDR provides LEDs that indicate received signal strength (RSS). These LEDs
are described in the table below:
LED
RSSI LEDs
(LO, MED, HI)
13070311-02
Color Status
Green All LEDs on
Two LEDs (LO; MED) on
One LED (LO) on
One LED (LO) blinking
All LEDs off
Airspan Networks Inc.
Q u i c k I n s t a l l a t i o n & C o n f i g u r a t i o n G u i d e
RSS level
(ASWipLL Release 4.2B and later)
RSSI ≥
-70 dBm ≤ RSSI <
-80 dBm ≤ RSSI <
-90 dBm ≤ RSSI <
RSSI <
TNC-type connector for
rd
3 party external
antenna
RJ-11 serial port
Molex 6-pin power port
-60 dBm
-60 dBm
-70 dBm
-80 dBm
-90 dBm
