Airspan ProST 4.9 Hardware Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IP-based
Broadband Wireless Access (BWA) System
605-0000-707 Rev C
ProST 4.9
Hardware Installation Guide
Connecting the World

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProST 4.9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Airspan ProST 4.9

Summary of Contents for Airspan ProST 4.9

  • Page 1 IP-based Broadband Wireless Access (BWA) System 605-0000-707 Rev C ProST 4.9 Hardware Installation Guide Connecting the World...

  • Page 2: Table Of Contents

    Table Of Contents Warnings and Notices .....................2 Radio Interference ......................2 Avoiding Radio Interference..................2 Modifications ......................2 General ........................2 Manufacturer's Disclaimer Statement ................2 Declaration of Conformity ....................3 European Community, Switzerland, Norway, Iceland, and Liechtenstein ......3 Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC......3 Preface.........................5 Purpose ........................5 Targeted Audience ......................5...
  • Page 3 Table Of Contents Ports ........................15 LEDs ........................16 Mounting ........................17 Wall Mounting......................17 Pole Mounting......................20 SDA-4S ........................23 Desktop Mounting ....................23 Wall Mounting......................24 Cabling The ProST......................26 Connecting ProST to SDA-1 ................... 27 Connecting ProST to SDA-4S ..................29 Connecting ProST to a Computer..................
  • Page 5 605-0000-707 ProST 4.9 Installation Guide...

  • Page 6: Warnings And Notices

    Failure to do so may void Airspan's AS.MAX product warranty and may expose the end user or the service provider to legal and financial liabilities. Airspan and its resellers or distributors are not liable for injury, damage or violation of regulations associated with the installation of outdoor units or antennas.

  • Page 7: Declaration Of Conformity

    Español: Este equipo cumple con los requisitos esenciales asi como con otras disposiciones de la Directive 1999/5/EC. Greek: ÌÅ ÔÇÍ ÐÁÑÏÕÓÁ Airspan ÄÇËÙÍÅÉ ÏÔÉ Ï ÅÎÏÐËÉÓÌÏÓ ÓÕÌÌÏÑÖÙÍÅÔÁÉ ÐÑÏÓ ÔÉÓ ÏÕÓÉÙÄÅÉÓ ÁÐÁÉÔÇÓÅÉÓ ÊÁÉ ÔÉÓ ËÏÉÐÅÓ Ó×ÅÔÉÊÅÓ ÄÉÁÔÁÎÅÉÓ ÔÇÓ ÏÄÇÃÉÁÓ 1999/5/ÅÊ. Français: Cet appareil est conforme aux exigencies essentialles et aux autres dispositions pertinantes de la Directive 1999/5/EC.
  • Page 8 605-0000-707 ProST 49 Installation User Guide-Rev C The Declaration of Conformity related to this product can be obtained from product_management@Airspan.com...

  • Page 9: Preface

    Purpose This guide provides step-by-step instructions for setting up and installing the ProST. Targeted Audience This guide is intended for the Airspan technician who is a qualified installer responsible for installing the ProST. Referenced Documentation For a description of the Web-based management tools for configuring and managing ProST, see...

  • Page 10: System Overview

    SDA-1) adapter. ProST connects to the SDA-1's 100BaseT interface port by a standard 100- meter CAT-5 cable. The SDA-1 also provides the ProST with 10 to 52 VDC power supply. However, as an alternative to the SDA-1 Type II adapter, Airspan offers two optional integrated LAN switches: SDA-4S Type II: integrated LAN switch, providing power and four 10/100BaseT ports for interfacing with the subscriber’s network...

  • Page 11: Architecture

    System Overview greater choice of access devices greater choice of interoperability between technologies High throughput providing fast access at burst data rates of up to 37 Mbps over a channel bandwidth of 10 MHz, and up to 18 Mbps over a channel bandwidth of 5 MHz Low cost Architecture The ProST system consists of the following components:...

  • Page 12: Prost Block Diagram

    605-0000-707 ProST 49 Installation User Guide-Rev C The ProST model with the N-type connector for connecting an external antenna is shown below: ProST Block Diagram The figure below displays the ProST block diagram: ProST Protocols Stack The figure below displays a block diagram of the ProST's network architecture, designed as a hierarchy of protocols (i.e.

  • Page 13: Theory Of Operation

    System Overview Theory of Operation For basic operation, the ProST requires no initial configuration--simply plug and play. Configuration is automatically performed over the air by the BS. The ProST is preconfigured by the operator at the BS (using Netspan) with service flow parameters such as the maximum information rate, the committed information rate, the maximum latency, and maximum jitter.

  • Page 14: Getting Started

    Package Contents Examine the AS.MAX shipping container. If you notice any damage, or missing items as listed in the Packing List, immediately notify the carrier that delivered the unit and contact an Airspan representative. The ProST kit should contain the following items:...

  • Page 15: Radio Site Planning

    Torque wrench for N-type connectors (only relevant when implementing external antenna) Note: Airspan does not provide screws and wall anchors for mounting the ProST to the wall. The screw size depends on the structure of the building to which the ProST is to be attached.

  • Page 16: Multipath Fading

    To avoid multipath fading from nearby buildings etc., Airspan recommends installing the ProST at the rear end of buildings instead of at the front. When you install at the rear end of the building, the front-end of the building blocks incoming signals from multipath reflections.

  • Page 17: Physical Description

    PHYSICAL DESCRIPTION This section provides a description of the components of the ProST installation: ProST radio (outdoor unit) SDA-1 adapter (indoor unit -- switch and power interface) SDA-4S Type II and SDA-4S/VL Type II adapters (optional) ProST The ProST is an encased outdoor radio providing access to communication ports on its front panel.

  • Page 18: Sda-1 Physical Description

    605-0000-707 ProST 49 Installation User Guide-Rev C SDA-1 Physical Description The SDA-1 is an integrated Ethernet and AC/DC power supply adapter that simply plugs into a standard electrical wall outlet (110/240 VAC). The SDA-1 provides the ProST with the following: 10/100BaseT interface with subscriber's network/PC 10 to 52 VDC power supply The SDA-1 enables easy plug prong replacement to suit geographical location of electrical outlet...

  • Page 19: Physical Dimensions

    Physical Description The SDA-4S Type II and SDA-4S/VL Type II indoor units (hereafter referred to as SDA-4S for convenience) are two optional integrated LAN switches that offer an alternative to the SDA-1 Type II unit. These two units have identical physical dimensions and design, as displayed in the figure below.

  • Page 20: Leds

    605-0000-707 ProST 49 Installation User Guide-Rev C determines the speed at which packets are transmitted through the specific SDA-4S port. For example, if the device to which the port is connected is running at 100 Mbps, the port connection will transmit packets at 100 Mbps. Conversely, if the device to which the port is connected is running at 10 Mbps, the port connection will transmit packets at 10 Mbps.

  • Page 21: Mounting

    Note: The standard ProST kit provides wall-mounting brackets. If you want to pole mount the ProST, contact your nearest Airspan distributor for pricing and ordering of pole-mounting brackets. Note: A minimum of 3-meter separation is required between mounted ProSTs and existing customer radio equipment when transmitting on different sectors (see figure below).
  • Page 22 (not supplied) through the mounting bracket holes into each wall anchor, and then tighten. Note: Airspan does not provide screws for attaching the mounting bracket to the wall. The screw size depends on the structure of the building to which the bracket is to be attached.
  • Page 23 Mounting Attach the ProST to the mounting bracket by performing the following: Slide an M10-spring lock washer and then an M10-plain washer onto each M10-hex head screw (ensure lock washer is nearest to head of screw bolt). Align the mounting bracket's holes with the ProST's mounting holes as displayed below. (The mounting bracket side that provides a groove for inserting a nut must be aligned with the ProST's mounting hole that is nearest to the ProST's rear panel.) From the external sides, insert the M10-hex head screws through the mounting...

  • Page 24: Pole Mounting

    605-0000-707 ProST 49 Installation User Guide-Rev C For wall mounting, rotation is restricted in the horizontal plane only, as shown in the figure below (top view): Pole Mounting Pole mounting allows the ProST to be easily adjusted in the horizontal (azimuth) and vertical (elevation) planes for antenna alignment.
  • Page 25 Mounting To pole mount the ProST: Attach the mounting bracket to the ProST: Align the mounting bracket with the ProST's mounting holes so that the mounting bracket's side with the built-in nut is aligned with the ProST's mounting holes furthest from the ProST's front panel, as shown in the figure below.
  • Page 26 605-0000-707 ProST 49 Installation User Guide-Rev C Attach the U-bolt to the pole: Place one U-bolt around the pole, and then insert the U-bolt screw side through the two corresponding holes (horizontally parallel) on the clamping bracket. Slide an M8-flat washer and M8-spring lock washer onto each U-bolt screw side (ensure that the flat washer is adjacent to the clamping bracket).

  • Page 27: Sda-4S

    Mounting ProST positioning is obtained in two planes by adjustment of the mounting bracket assembly as shown below: It is important to provide strain relief and drip loop for Cat-5 cables. Create a drip loop and strain relief using cable tie, to tie cable to pole, as displayed in the figure below: SDA-4S The SDA-4S adapters can be mounted either horizontally on a desktop or vertically on a wall.

  • Page 28: Wall Mounting

    605-0000-707 ProST 49 Installation User Guide-Rev C Warning: To prevent a fire hazard caused by overheating, do not place the SDA-4S on a carpeted surface where airflow is restricted. Wall Mounting Wall mounting is made possible by the existence of two mounting hooks molded into the SDA-4S's bottom panel, as displayed in the figure below.
  • Page 29 Mounting Drill holes for each hole that you marked in the step above. Insert wall anchors (supplied) into each of the drilled holes. Insert the 9-inch screws (supplied) into the wall anchors. Ensure at least 2 mm of the screw is exposed to allow insertion into the SDA-4S mounting holes. Hold the SDA-4S with both hands, and align the entrance to the two mounting hooks with the screws.

  • Page 30: Cabling The Prost

    CABLING THE PROST The ProST interfaces with the subscriber's network through the IDU (i.e. typically the SDA-1 Type II, or optionally through the SDA-4S Type II or SDA-4S/VL Type II). The ProST also receives DC power from the IDU. This section describes the ProST cabling: Connecting ProST to SDA-1 Connecting ProST to SDA-4S Connecting ProST to a Computer...

  • Page 31: Connecting Prost To Sda-1

    Cabling The ProST CONNECTING PROST TO SDA-1 The ProST connects to the SDA-1 using a CAT 5 cable with 8-pin RJ-45 connectors on either end. The ProST provides a 15-pin D-type port for interfacing with the SDA-1. However, for allowing the use of RJ-45 connectors, your ProST kit includes a DB15-to-RJ45 adapter that can easily be attached to the ProST's 15-pin D-type port.
  • Page 32 605-0000-707 ProST 49 Installation User Guide-Rev C...

  • Page 33: Connecting Prost To Sda-4S

    Cabling The ProST CONNECTING PROST TO SDA-4S The ProST connects to the SDA-4S or SDA-4S/VL using a CAT 5 cable with 8-pin RJ-45 connectors on either end. The ProST provides a 15-pin D-type port for interfacing with the SDA- 4S. However, for allowing the use of RJ-45 connectors, your ProST kit includes a DB15-to-RJ45 adapter that can easily be attached to the ProST's 15-pin D-type port.
  • Page 34 605-0000-707 ProST 49 Installation User Guide-Rev C...

  • Page 35: Connecting Prost To A Computer

    Warning: Only subscriber terminal equipment (e.g. computer modem port) that is designed for full compliance with TNV-1 telecommunication network connectivity can be connected to the SDA-1. Warranty of Airspan's equipment shall be made void if the SDA-1 is connected to a computer that is not compliant with TNV-1.

  • Page 36: Using The Sda-4S Type Ii Or Sda-4S/Vl Type Ii

    605-0000-707 ProST 49 Installation User Guide-Rev C Using the SDA-4S Type II or SDA-4S/VL Type II The SDA-4S Type II or SDA-4S/VL Type II adapters (referred hereafter as SDA-4S) provide one four RJ-45 (10/100BaseT) ports for interfacing with the subscriber's LAN network. The difference between these two adapters is that the SDA-4S/VL supports VLAN functionality at the ports.
  • Page 37 Cabling The ProST Straight-through cable (e.g. connecting to a PC) Function 8-Pin RJ-45 Crossover cable (e.g. connecting to a hub) Function Function 8-Pin RJ-45...
  • Page 38 605-0000-707 ProST 49 Installation User Guide-Rev C...

  • Page 39: Connecting Power

    SDA-4S Type II adapters is the method of connectivity to the power outlet, as discussed in the subsections below. Airspan can also provide lightning and surge protection for the SDA-1 to protect the data and power interfaces from electrical surges caused when lightning strikes the ODU/IDU Cat 5 cable.

  • Page 40: Plugging The Sda-1 Into An Electrical Wall Outlet

    605-0000-707 ProST 49 Installation User Guide-Rev C On the rear of the SDA-1, slide the locking switch to OPEN. Remove the prongs by sliding the prongs in the direction away from the switch. Insert the desired prongs by aligning the prongs with the SDA-1's prong groove, and then sliding the prongs onto the SDA-1 until it reaches the end of the groove.

  • Page 41: Using Sda-4S Type Ii And Sda-4S/Vl Type Ii

    Cabling The ProST Verify that your SDA-1 is on and receiving power by checking that the green LED light (labeled POWER) on the SDA-1's front panel is lit. If it is not, see Appendix C, "Troubleshooting". Using SDA-4S Type II and SDA-4S/VL Type II The SDA-4S adapters are plugged into a standard electrical wall outlet (110/240 VAC) using an AC power cord.

  • Page 42: Connecting The Lightning And Surge Protector

    605-0000-707 ProST 49 Installation User Guide-Rev C Connecting the Lightning and Surge Protector The third-party (PolyPhaser) lightning and surge protector for the SDA-1 is implemented in the following deployment scenarios: IDU/ODU cable connectivity of 40 meters or more (mandatory) Deployment of ProST in geographical areas that often experience severe lightning storms The lightning and surge protector protects the CAT 5's six used wires (two -48 VDC wires and four Ethernet Tx and Rx wires) from any electrical surge due to a lighting strike.
  • Page 43 Cabling The ProST Feed the CAT 5 cable through the grommet (for each side). If the RJ-45 connector is already crimped to the other end, ensure that you have fed the cable through the gland nut beforehand. The gland nut secures the cable to the grommet. Strip about 0.25"...
  • Page 44 605-0000-707 ProST 49 Installation User Guide-Rev C...

  • Page 45: Specifications

    SPECIFICATIONS This section includes the following specifications: ProST SDA-1 Type II adapter SDA-4S Type II and SDA-4S/VL TypeII Lightning and Surge protector ProST Specifications The ProST's specifications are listed in the table below: Category Parameter Value Radio WiMAX Frequency 4.9 to 5.0 GHz Technology band Duplex...
  • Page 46 605-0000-707 ProST 49 Installation User Guide-Rev C EN 300 328 2.4 GHz Part 15 15.247- 2.4 GHz Safety EN/IEC/UL 60950 Environmental EN 300 019-2-2 EN 300 019-2-4 Networking WiMAX Protocols Transparent Bridging IP type of service Protocol IP source address IP destination address Protocol source port Protocol destination port...

  • Page 47: Sda-1 Type Ii Specifications

    Specifications SDA-1 Type II Specifications The SDA-1's specifications are listed in the table below: Category Parameter Value Interfaces Network Two 10/100BaseT (for interfacing with ProST radio and subscriber's PC/LAN) Mechanical Two 8-pin RJ-45 ports (for 10/100BaseT interface with ProST radio and subscriber's PC/LAN) Standards Safety...

  • Page 48: Lightning/Surge Protector Specifications

    605-0000-707 ProST 49 Installation User Guide-Rev C ProST) AC power socket Standards Safety UL/CUL UL60950, TUV EN60950, CB compliance BN55022 EMI/RFI VDE and FCC limit B Environmental Operating 0 to +40°C temperature Storage -20 to +85°C temperature Humidity 5 to 96% RH non-condensing Power Requirements 110/240 VAC, 50/60 Hz (standard...
  • Page 49 Specifications (24 or +/- 32, < 0.02 2.0 Adc DC24 48Vdc) +/- 53 Vdc Ohms Power Supply, dc DC48 voltage...

  • Page 50: General

    GENERAL CONTACT INFORMATION UK Office for sales and general enquiries Airspan Communications Ltd Cambridge House Oxford Road Uxbridge Middlesex UB8 1UN Call +44 (0) 1895 467100 Fax +44 (0) 1895 467101 email sales@ airspan.com Internet: Airspan.com Customer Service Help-Desk for customer service emergency...

  • Page 51: Copyright Information

    COPYRIGHT INFORMATION Airspan Networks Inc 2006 The information in this document is proprietary to Airspan Networks Inc. This document may not in whole or in part be copied, reproduced, or reduced to any medium without prior consent, in writing, from Airspan Networks Inc.

  • Page 52: Glossary

    GLOSSARY 802.1X: IEEE standard for network access control to LAN users by allowing or preventing access determined by authentication. AES: Advanced Encryption Standard. A block cipher adopted as an encryption standard by the US government. AES has a fixed block size of 128 bits and a key size of 128, 192 or 256 bits.
  • Page 53 Glossary ISP: Internet Service Provider L2PT: Layer 2 Protocol Tunneling LAN: Local-Area Network MAC: The next layer up from the PHY, known as the media access controller Mbit/s: Megabits per second MHz: Megahertz (one million cycles per second) MIB: Management Infomation Base NAS: Network Access Server NLOS: Non Line of Sight radio propagation path ODU: Out door unit associated with a ST...
  • Page 54 605-0000-707 ProST 49 Installation User Guide-Rev C SNR: Signal-to-Noise Ratio SSIS: Service Set Identifier ST: Subscriber Terminal (interchangeable with CPE or SS) TCP: Transmission Control Protocol TDMA: Time Division Multiple Access. Technology for delivering digital wireless service using time-division multiplexing (TDM) TKIP: Temporal Key Integrity Protocol.

  • Page 55: Index

    INDEX Architecture ......... 6 Modulation technologies ......6 Bandwidth speeds ......... 6 Operating frequency band.......6 Benefits..........6 Physical Dimensions......14 Components......... 6 Ports Description ........14 Features ..........6 Theory of operation .......6...
  • Page 56 How to find out more about Airspan products and solutions For more information about Airspan, its products and solutions, please visit our Airspan has offices in the following Web site: countries: www.airspan.com Europe Czech Republic Or write to us at one of the addresses below.
