Enabling Trap Display In Wipmanage - Airspan ASWipLL Quick Installation And Configuration Manual

Q u i c k I n s t a l l a t i o n & C o n f i g u r a t i o n G u i d e

12.2. Enabling Trap Display in WipManage

WipManage can display up to the last 1,000 received traps, which are displayed in WipManage main window's
Traps pane.
To enable WipManage to display traps:
1. In the WipManage main window, from the Tools menu, choose Environment Settings.
Selected check box to
display traps
2. Click the Trap Settings tab.
3. Select the Add Traps to List check box. (To save traps to the WipManage database, select the Add
Traps to DB check box.)
4. Click OK.
Notes:
1) Traps are displayed with a specific severity level: Normal
2) To show the Traps pane, in the WipManage main window, from the View menu, choose Traps Pane.
3) To receive traps, ensure the Stop Listening
window's toolbar. If the Start Listening button is displayed, click this button.
4) Traps that are saved in the DB appear in the Traps pane with an index number, e.g. "2"; traps not saved in
the DB appear with a number sign (#) alongside the index number, e.g. "#2"; traps from a previous
WipManage session and not saved in the DB appear with "Old" alongside the index number, e.g. "Old 2".
30
button is displayed (default) on the WipManage main
Airspan Networks Inc.
, Warning , Major , and Critical
AS W i p L L 9 0 0 M H z
Traps pane
displaying
received traps
.
13070311-02
