Q u i c k I n s t a l l a t i o n & C o n f i g u r a t i o n G u i d e

Establishing Link using WipManage

Once you have initialized the BSR and SPR/IDR using WipConfig, you need to add various WipManage
elements to establish a viable air and network link between the BSR and SPR/IDR.

11.1. Adding a BS Group

A BS Group is the first element you need to define in WipManage.
To add a BS Group:
1. In the Database Tree, right-click
BS Group Add dialog box appears.
2. In the Group Name field, enter a name for the BS Group, e.g. "Manhattan_1", and then click OK.

11.2. Adding a BS

You can now add a Base Station (BS) to the BS Group you added in the previous subsection.
To add a BS:
1. In the Database Tree, click the
2. In the BSs Map view (in the right pane), right-click an empty area, and then from the shortcut menu,
choose Add BS; The BS Add dialog box appears.
3. In the BS Name field, enter a name for the BS, e.g. "Times Square", and then click OK.
26
, and then from the shortcut menu, choose Add BS Group; The
(e.g. "Manahattan_1") branch to which you want to add the BS.
