Summary of Contents for Airspan AirVelocity 1500
- Page 1 AirVelocity 1500 Installation Guide Part Number: DUG01560 System Release: 16.5 Revision: A Published: March 2019...
- Page 2 No responsibility is assumed by Airspan Networks Ltd. for the use of the documents nor for the rights of third parties which may be effected in any way by the use thereof. The provision of these documents (and the documents themselves) does not constitute professional advice of any kind.
-
Page 3: Table Of Contents
About This Document ................9 Purpose ........................9 Intended Audience ....................9 Document Conventions ..................9 Related Reading ....................9 Customer Care Help Desk ..............10 Airspan Encourages Comments ................10 1 Introduction ..................11 DUG01560 Airspan Commercial and Internal Use... - Page 4 AirVelocity 1500 Installation Guide 1.1 AirVelocity 1500 .................... 11 2 Getting Started ..................12 2.1 AirVelocity 1500 Installation Checklist ............12 3 Verifying Prerequisites ................. 13 3.1 Verifying Site Requirements ................13 3.2 Verify Installation Requirements ..............13 3.2.1 Verify the Tools .................... 13 3.2.2 Verify the Parts and Kits ................
- Page 5 Figure 19: DC In - Panel ........................26 Figure 20: GPS Antenna ........................27 Tables Table 1: AirVelocity 1500 ETSI / FCC Maximum Output TX Total Power ..........7 Table 2: Supported Frequency Bands ....................7 Table 3: Power Consumption ......................7 Table 4: Integral Sector Antenna Parameters (LTE) ................
-
Page 6: Document Information
Table 13: LED Display ........................25 Table 14: GPS Kit Contents ......................27 Table 15: ABBREVIATIONS & DEFINITIONS .................. 31 Document Information Abstract This document details procedures for installing the Airspan’s AirVelocity 1500 Indoor-Pico Enterprise eNodeB variant. Revision History Revision Details Date Summary of Changes ... -
Page 7: Warnings And Cautions
Radio Interference This AirVelocity 1500 generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 8: Warning Of Hazardous Voltages
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances Regulations 1990). At the end of any Airspan products life cycle, the customer should consult with Airspan to ensure that the product is disposed of in conformance with the relevant regulatory requirements. -
Page 9: Adherence To European Directive 2014/53/Eu
UL Information - The electrical source must be properly grounded according with NEC and other local safety code requirements. - AirVelocity 1500 is designed to operate in environmental conditions complying with IP40 and relevant standards. DUG01560 Airspan Commercial and Internal Use... -
Page 10: Declaration Of Conformity
This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Español: Por medio de este Airspan, declara que la unidad cumple con los requisitos esenciales y cualquier otra disposición aplicable o exigible de la Directiva 2014/53 / UE. Greek: ΜΕ... - Page 11 2014/53 / EU. Íslenska: Airspan lýsir hér með yfir að þessi eining uppfylli grunnkröfur og aðrar kröfur tilskipunar 2014/53 / ESB. Norsk: Airspan erklærer herved at utstyrsenheten oppfyller grunnleggende krav og andre relevante krav i direktiv 2014/53 / EU.
-
Page 12: Maximum Output Tx Total Power
VNG15-U48-B08P3D 3550 - 3700 3550 - 3700 20.99dBm Power Consumption AirVelocity 1500 has a maximum nominal power consumption of 30W. AirVelocity 1500 power consumption is described in the following table: Table 3: Power Consumption LTE Tx Power Before Nominal Power... -
Page 13: Lte Antenna System
Use of an external antenna is not part of the product design. LTE Antennas AirVelocity 1500 has a sectorial antenna that behaves as an Omni antenna for ceiling mount and Directional antenna for wall mounting. The integral LTE antenna included is dependent on the product’s LTE band. -
Page 14: About This Document
Install GPS Antenna (if required) Connect and manage cables Intended Audience This guide is intended for persons who are responsible for installing the AirVelocity 1500 equipment. These persons should have a working knowledge of LTE. Document Conventions This document uses the following typographic conventions. -
Page 15: Customer Care Help Desk
Customer Care Help Desk Airspan’s Customer Care Help Desk offers prompt and efficient customer support services. To avail Airspan’s Customer Care Help Desk support, you must be a registered user and must Note: have a valid support contract. To register, click here and fill the Registration form. -
Page 16: Introduction
This super compact pico product minimizes physical footprint, power consumption and operator OPEX. AirVelocity 1500 LTE radio implements a quad 25 dBm (4 x 315mW) transmit channels, with an integral antenna. -
Page 17: Getting Started
AirVelocity 1500 Installation Guide 2 Getting Started 2.1 AirVelocity 1500 Installation Checklist Plan the installation of the AirVelocity 1500 by using the Installation Checklist, which you can find as a removable job aid in Appendix B for this guide. DUG01560... -
Page 18: Verifying Prerequisites
AirVelocity 1500 Installation Guide 3 Verifying Prerequisites Prior to installing the AirVelocity 1500, verify the required safety, power, tools, parts and components. This chapter includes the hardware, software, and client requirements for installation. Important: Set up requirements for the installation is detailed in the Job Sheet, see Appendix 3.1 Verifying Site Requirements... -
Page 19: Power Supply
RJ45 POE++ Operational Voltage Range: 50.0–57.0 Vdc, IEEE802.3bt class 6 DC port Operational Voltage Range: 9-14Vdc AC to POE++ injector or AC to DC power supply are not included with the AirVelocity 1500 and can be ordered separately. Table 8 AirVelocity 1500 Power Supply Options Installation Kit / Part Part No. -
Page 20: Physical Dimensions
AirVelocity 1500 is shown below displaying the Copper Ethernet ports and the GPS connection panel. Figure 2: AirVelocity 1500 Ports (DC Variant) 3.2.5 Physical Dimensions 3.2.5.1 Dimensions AirVelocity 1500 is an indoor enclosure. Below are the AirVelocity and related parts dimensions (H x W x D): Table 10. AirVelocity 1500 Physical Dimensions Part... -
Page 21: Environmental
AirVelocity 1500 Installation Guide 3.2.6 Environmental Note: AirVelocity 1500 is not for external/outdoor use. AirVelocity 1500 meets the following environmental requirements: ETSI EN 300-019-1-3 Operational (weather protected locations) ETSI EN 300-019-1-1 Storage (weather protected, not temperature controlled locations) ... -
Page 22: Airvelocity 1500 Installation
Rail plate – used for mounting on a suspended ceiling – 4 provided Rail bracket (with screws, M5x 8mm x4) in AirVelocity 1500 package – to be attached to the AirVelocity unit for ceiling mount (suspended or conventional) & wall mount. -
Page 23: Figure 4: Assemble Rail Plates To The Mounting Plate
AirVelocity 1500 Installation Guide Figure 4: Assemble Rail Plates to the Mounting Plate At the pre-determined juncture of the suspended ceiling’s rail supports, position the assembled Mounting plate & rails onto the suspended ceiling’s rail supports. Figure 5: Ceiling Mounting Plate & Rails onto Ceiling Rails Slide the triangular Rail plates (4) so that they clinch the ceiling rails at the rail’s... -
Page 24: Figure 7: Engage The Rail Brackets Projections Into The Ceiling Plate Slots
AirVelocity 1500 Installation Guide Figure 7: Engage the Rail Brackets Projections into the Ceiling Plate Slots After the Rail bracket projections are in the slots swing the unit into the other side of the Ceiling mounting plate, insert and secure the Locking pin (supplied) through the hole on Rail bracket and the Ceiling mounting plate. - Page 25 AirVelocity 1500 Installation Guide Remove the plastic cover to expose the connectors. Connect the necessary cables to the relevant ports. Connect to power Copper Ethernet port – ETH – if applicable Fiber Ethernet port – SFP – if applicable ...
-
Page 26: Conventional Ceiling Assembly
Figure 11: Attach Mounting Bracket to Standard Ceiling Mounting plate is installed and ready for AirVelocity 1500 mounting. Note: Screws and washers (x4) and any necessary hardware are not supplied by Airspan and are the responsibility of the installer. Use appropriate ceiling hardware according to field conditions. -
Page 27: Figure 12: Mounting Airvelocity 1500 On Conventional Ceiling
AirVelocity 1500 Installation Guide Figure 12: Mounting AirVelocity 1500 on Conventional Ceiling Once the rail bracket projections are in the slots swing the unit into the other side of the Ceiling mounting plate insert and secure insert and secure the Locking pin (supplied) through the hole on Rail bracket and the Ceiling mounting plate. -
Page 28: Wall Mount Assembly
Drill the four (4) holes. After drilling insert wall plugs (x4) (not included). Note: Wall plugs (x4) and necessary hardware are not supplied by Airspan and are the responsibility of the installer. Use appropriate wall plugs according to field conditions. -
Page 29: Figure 16: Insert Anchors & Screws In Wall
AirVelocity 1500 Installation Guide Figure 16: Insert Anchors & Screws in Wall Push down slightly to engage the heads of the screws onto the slots. Figure 17: Push Down to Engage Screw Heads DUG01560 Airspan Commercial and Internal Use... -
Page 30: Led Display
AirVelocity 1500 Installation Guide Remove the plastic cover to expose the connectors. Connect the necessary cables to the relevant ports. Connect to power Copper Ethernet port – ETH – if applicable Fiber Ethernet port – SFP – if applicable ... -
Page 31: Connect And Manage Cables
This takes up any excess slack and presents a more thorough and orderly installation. 5.3.1 Copper Ethernet Cable Typical RJ45 connection (when applicable). 5.3.2 Fiber Ethernet (SFP) Cable SFP module and connector (when applicable), not supplied by Airspan. DUG01560 Airspan Commercial and Internal Use... -
Page 32: Gps Antenna Mounting
AirVelocity 1500 Installation Guide 6 GPS Antenna Mounting 6.1 Verify the Parts and Kits Table 14: GPS Kit Contents Item Image Active GPS Antenna 10m GPS Cable - RG58 SMA-F to SMA-M GPS Antenna Mounting Bracket Double Sided Sticker Note: The GPS antenna is an active antenna. - Page 33 AirVelocity 1500 Installation Guide Option 2 – installation on the outside of a window 1. Remove the paper from one side of the double sided sticker and attach the sticker on the back side of the antenna. 2. Thoroughly clean the area of the window where you intend to attach the GPS antenna.
-
Page 34: A Job Sheet
AirVelocity 1500 Installation Guide A Job Sheet This job sheet enables the users to keep track of their installation. It covers all the prerequisites required for accomplishing the AirVelocity 1500 installation. Site Requirements Position on ceiling / wall Access restrictions (local regulations) (when applicable) -
Page 35: B Checklist
B Checklist During installation, review and perform all the steps on this checklist (in the given order). This checklist is meant for the person who performs the AirVelocity 1500 installation. Tip: To make sure you complete all the tasks, detach or print this checklist and use it as a job aid. -
Page 36: C Abbreviations
AirVelocity 1500 Installation Guide C Abbreviations Table 15: ABBREVIATIONS & DEFINITIONS Term Definition 3GPP 3rd Generation Partnership Project, responsible for LTE Adjacent Channel Selectivity is a measurement of a receiver's ability to process a desired signal while rejecting a strong signal in an adjacent frequency channel.
