Installing Wipmanage - Airspan ASWipLL Quick Installation And Configuration Manual

AS W i p L L 9 0 0 M H z

7.2. Installing WipManage

The WipManage program is supplied on a CD-ROM.
To install WipManage:
1. Insert the WipManage CD into your CD-ROM drive.
2. On the Window's taskbar, click Start, and then choose Run.
3. Browse the WipManage CD, and then double-click wipmng.exe. The installation wizard starts.
4. Click Next to begin the installation.
5. Click Next to agree to the terms of the license agreement and continue with the setup.
6. Click Next to install WipManage in the default directory C:\WipMng.
7. Click Next to add WipManage to the "Airspan" Program Manager Group.
8. If Microsoft Access is not installed on your PC, select the Add MS-Access ODBC Drivers check box.
9. Select the Add Data Source check box if you are performing a first-time installation of WipManage, and
then click Next.
10. Enter the Customer Key to continue the installation, alternatively, leave the Customer Key field empty,
and then click Next to continue.
11. Click Next to begin installing WipManage. If you selected the Add Data Source check box in Step 9, the
ODBC Microsoft Access Setup dialog box appears.
In the ODBC Microsoft Access Setup dialog box, accept the settings, and then click OK to continue
installation. The WipManage wiplldb.mdb file will be created in the directory C:\WipMng\wiplldb.mdb.
12. When the installation has completed, click Finish to close the wizard.
Note: WipManage does not receive traps if you have a firewall. In such a setup, the outbound UDP port 161
(SNMP) must remain open.
13070311-02 Airspan Networks Inc.
Q u i c k I n s t a l l a t i o n & C o n f i g u r a t i o n G u i d e
19
