Operating Temperature Range
CC
Pirani
CEP
CM
TC
Maximum Bakeout Temperature
(Without Controller or Cables)
CC
Pirani
CEP
CM
TC
Diameter
CC
Pirani
CEP
CM
TC
20
Series 421 - 0° to 70°C
(32° to158°F)Special available that
operates up to 200°C.
Series 423 - 0° to 70°C
(32° to158°F)
0° to 50°C (32° to 122°F)
10° to 50°C (50° to 122°F)
0° to 50°C (32° to 122°F)
0° to 40°C (32° to 104°F)
Series 421 – 250°C (482°F) when
backshell subassembly removed,
125°C (257°F) otherwise ;
Series 423 – 400°C (752°F) CF
flange version only with magnet
removed
50°C (122°F)
150°C (302°F)
100°C (212°F) RF shielded
N/A
60°C (140°F)
Series 421 – 2.2 in. (56 mm)
Series 423 – 2.6 in. (66 mm)
1.3 in. (34 mm)
1.6 in. (41 mm)
Type 122 - 3.0 in. (76 mm)
Types 622 and 626 - 2.6 in. (66 mm)
Type 722- 1.5 in. (38 mm)
1.3 in. (34 mm)
