1.3 Printer Components

1.3.1 Component and function

Front cover
Control panel
Card eject slot
Part name
Top cover
Front cover
Thermal print head Core component of the printer.
Control panel
Card eject slot
Knob
DC-3300
Thermal print head
Function
Protects the print head and the internal components. Open
to replace the ribbon.
Open to load cards. Max. 100 pieces of 0.76mm thickness
cards can be placed.
Includes the keys, the LCD Panel, and LED indicator for
operating the printer.
Ejects printed cards.
If the jammed card can not be ejected, power off the printer
and turn the knob.
5
User Manual v1.0
Top cover
Knob
