Dascom DC-3300 User Manual page 55

2) Press【 Menu /Exit】 Key for 3 second then release it. The LCD shows [Choose mode]. Press
▲ or ▼ Keys to select User Mode or Service Mode:
Ready
Even when the printer is in an error state, you can change modes.
 Steps to return to Normal Mode fromUser Mode:
Continually press Menu/Exit Key until the LCD shows [Quit the Menu]. Then press SET Key to
return to Normal Mode:
Function of four keys in User Mode:
 Menu/Exit Key:


 SET Key: an affirmative response to the second line in the LCD.
 Moving between menus in the same level:
Section 3.3 lists out eleven menus in the same level, from Printer Info, Version Info, ...
Reset User Default. Consecutively pressing ▼/▲ keys scrolls through the various menus. It
doesn't mater which arrow key is pressed since the menus loop around. But when the desired
Menu is displayed, press the SET key.
DC-3300
Menu/Exit
Quit the Menu？
back to its parent menu, i.e. one level up in the menu hierarchy.
▲ Key: previous item.
▼Key: next item.
Choose mode
User Mode
Choose mode
Service Mode
Yes
41
User Manual v1.0
to
