Basic assembly

Lens tube
Color frame
retainer clip
Color frame
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, EXPOSURE
TO EXCESSIVE UV RADIATION, OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING - To reduce the risk of FIRE, ELECTRIC SHOCK, EXPOSURE TO
EXCESSIVE UV RADIATION, OR INJURY TO PERSONS:
1) Do not touch hot lens, guard, or enclosure.
2) Do not remain in light if skin feels warm.
3) Do not look directly at lighted lamp.
4) Keep lamp away from materials that may burn.
5) External temperature after 5 minutes of full-brightness operation
50°C (122°F).
6) External temperature when steady state is achieved 67°C (152.6°F).
SAVE THESE INSTRUCTIONS
2
Yoke
Pattern
holder slot
Shutter barrel
Beam focus knob Shutters x4
Source Four Mini LED User Manual
Safety cable
attachment
point
