Installing a track fixture

WARNING:
AVERTIR:
1: Insert the track adapter into the
track. The adapter will only fit one
way into the track with the tabs of
the adapter in the groove of the
track.
2: Lock the adapter into place.
3: Select circuit 1 or 2 using the circuit
selection wheel. (The 230V track
adapter has a three-circuit selector
knob.)
4: Focus the fixture.
5: Lock the fixture into place using the yoke lock.
Cable protection posts on
both the yoke lock and the
yoke prevent the fixture
from rotating a full 360°.
To lock the yoke in place
use a 1.5 mm Allen wrench.
6
To reduce the risk of fire and electric shock, use the
track-mount fixture only with the DataTrack (EUTRAC)
track system.
Pour éviter le risque d'incendie ou de choc électrique
avec le modèle adaptateur pour rail, utiliser uniquement
avec une alimentation par rail DataTrack (EUTRAC).
Tabs
Circuit
selection wheel
Source Four Mini LED User Manual
Lock
