B a s i c A s s e m b l y
Lens tube
(sold separately)
Color frame
retainer clip
Color frame
INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR INJURY TO
PERSONS
IMPORTANT SAFETY INSTRUCTIONS
Lighted lamp is HOT!
WARNING - To reduce the risk of FIRE OR INJURY:
1) Turn off power and allow to cool before replacing lamp.
2) Lamp gets HOT quickly! Contact only switch/plug when turning on.
3) Do not touch hot lens, guard, or enclosure.
4) Keep lamp away from materials that may burn.
5) Do not touch the lamp at any time. Use a soft cloth. Oil from skin may damage
lamp.
6) Do not operate the luminaire with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
Yoke
Pattern Holder
Slot
Shutter Barrel
Beam focus
knob
Lamp housing
Safety attachment
point
Shutters x4
Lamp housing
knob
