DHC-1 CHIPMUNK
Instruction Manual.
Control horn.
Metal clevis.
M2 lock nut.
Elevator pushrod.
Wire keeper.
INSTALLATION PILOT AND CANOPY.
1) Locate items necessary to install pilot
and canopy.
RUDDER PUSHROD HORN
INSTALLATION.
2) A scale pilot is included with this ARF.
The Pilot included fitting well to the cock-
pit. (or you can order others scale pilot
figures made by SG Models. They are
available at SG Models distributors.)
28
