DHC-1 CHIPMUNK
INSTALL ELEVATOR CONTROL HORN.
Fiberglass control horn
INSTALLING VERTICAL STABILIZER
24
Epoxy.
Epoxy.
Instruction Manual.
1) While holding the vertical stabilizer
firmly in place, use a pen and draw a
line on each side of the vertical stabilizer
where it meets the top of the fuselage.
2) Slide the vertical stabilizer back in place.
Using a triangle, check to ensure that the ver-
tical stabilizer is aligned 90º to the horizontal
stabilizer.
Horizontal
90º
Stabilizer.
FillE poxy.
Vertical
Stabilizer.
