TrimTrac Application Protocol Message Summary (Sorted by Header)
Message Name
Header
>QTK{x} QUERY_CONFIG
>QTKD QUERY_POSITION
QUERY_METERS
>QTKM
>QTKR QUERY_LOG
>QTKU QUERY_CONTROL_OUTPUTS
>RTK{1-4} RESP_QUERY_AGGR
>RTKA RESP_APP_CONFIG
>RTKF RESP_GPRS_CONNECT_CONFIG
>RTKG RESP_GPS_CONFIG
>RTKJ RESP_GPRS_SETUP_CONFIG
>RTKK RESP_GEOFENCE_CONFIG
>RTKL RESP_ALERT_STATE
>RTKM RESP_METERS
>RTKP REPORT_POS
>RTKR RESP_QUERY_LOG
>RTKS STATUS_MSG
>RTKU RESP_CONTROL_OUTPUT
>RTKV RESP_PROV_CONFIG
>RTKX RESP_EXT_APP_CONFIG
RESP_MODULE_APP_CONFIG
>RTKY
>RTKZ RESP_EXT2_APP_CONFIG
>STKA SET_APP_CONFIG
>STKF SET_GPRS_CONNECT_CONFIG
>STKG SET_GPS_CONFIG
>STKJ SET_GPRS_SETUP_CONFIG
>STKK SET_GEOFENCE_CONFIG
>STKL SET_ALERT_STATE
>STKU SET_CONTROL_OUTPUT
>STKV SET_PROV_CONFIG
>STKX SET_EXT_APP_CONFIG
SET_MODULE_APP_CONFIG
>STKY
>STKZ SET_EXT2_APP_CONFIG

Table 102, TrimTrac Application Protocol Messages (Sorted by Header)

Description
Requests current configuration settings where x=A,F,G,J,K,V,X,Y or Z
Requests current or logged position information
Requests/Clears current state of Runtime Meters
Requests logged messages (REPORT_POS and STATUS_MSG)
Requests current status of Control Module outputs
Reports summary of two logged messages
Reports current Basic Application parameters
Reports GPRS Configuration
Reports GPS parameters
Reports GPRS Setup
Reports Geofence parameters
Reports acknowledgment or, if conditions all normal, clearing of alerts
Reports Runtime meter readings
Basic position message
Reports requested logged messages
Same as REPORT_POS except no location/altitude/velocity data
Reports current Control Module Output condition
Reports current SMS Communication parameters
Reports current Extended Application parameters
Reports current Module application parameters
Reports Scheduled Hours, Runtime Meters and other parameters
Changes Basic Application parameters
Changes GPRS Configuration
Changes GPS parameters
Changes GPRS Setup
Changes Geofence parameters
Acknowledges or clears Module alerts
Controls Control Module Outputs
Changes SMS Communication parameters
Changes Extended Application parameters
Changes module application parameters
Changes Scheduled Hours, Runtime Meters and other parameters
See Page
TrimTrac ProE Locator Technical Manual v2.0e 210
161
164
164
161
166
179
170
176
175
177
175
169
178
167
179
167
181
178
171
180
173
148
155
156
156
154
147
149
157
149
158
152
