SET_CONTROL_OUTPUT
This message is sent by the server to set the Control Module Output pins to the
desired state. When received the device will send a RESP_CONTROL_OUTPUT
(page 181) message.
>STKABCDDDDDDDDDDDDDDDD;PW=PPPPPPPP;ID=YYYYYYYY;*ZZ<
A Always 'U': Indicates a set Control Module output message.
B
Output 1: 0=Output Low; 1=Output High; 2=No Change.
C
Output 2: 0=Output Low; 1=Output High; 2=No Change.
DDDD Reserved for future use. 16 digits. Must be sent as
DDDD
'0000000000000000'.
DDDD
DDDD
PPPPPPPP
Security Password
CASE ONLY.
YYYYYYYY
Unit ID. Always 8 alphanumeric characters, UPPER CASE ONLY
ZZ Checksum.

Table 59, SET_CONTROL_OUTPUT Message

.
Always 8 alphanumeric characters, UPPER
Default 00000000
