SET_GEOFENCE_CONFIG
This message is used to set up a Geofence in the TrimTrac ProE device. When
received the TrimTrac ProE device will send a RESP_GEOFENCE_CONFIG
(page 175) message in response. Please note that all geofences must be the same
type (Boundary Crossing, Exclusive, Inclusive) as determined by either
SET_EXT2_APP_CONFIG (page 152) or AT+CTKZ (page 134).
>STKABBCDEEEEEFFFFFGGGHHHHHHHIIIIJJJJJJJ;PW=PPPPPPPP;I
D=YYYYYYYY;*ZZ<
A
TrimTrac ProE Configuration Set: 'K' = Geofence Parameters
BB Geofence ID: Unique geofence identifier 1 or 2.
C
Geofence Enforcement: 0=Disabled; 1=Enforced; 2=LPA Input
Enforced; 3=LPA Centered and Enforced.. Default 0
D Geofence Schedule: 0=24/7; 1=After Scheduled Hours; 2=
During Scheduled Hours. (See Scheduled Hours Mode). Default:
0
EEEEE
Geofence Delta X: 100s of meters (1 – 10000) Note: East-West
length of rectangular Geofence area or, if circular, the diameter.
1=100 Meters. Default 1.
FFFFF
Geofence Delta Y: 100s of meters (0, 1 – 10000) Note: If set to
"0", then circular Geofence area; else rectangular Geofence area.
1=100 Meters
GGG.HHHH
Geofence Center Latitude:
HHH
to 7 decimal places plus '+' sign = North and '-' = South.
(-90.0000000 to +90.0000000)
IIII.JJJ Geofence Center Longitude:
JJJJ
Degrees to 7 decimal places plus '+' sign = East and '-' = West.
(-180.0000000 to +180.0000000)
PPPPPPPP
Security Password
ONLY.
YYYYYYYY Unit ID. Always 8 alphanumeric characters, UPPER CASE ONLY
ZZ
Checksum.

Table 62, SET_GEOFENCE_CONFIG Message

WGS-84 Coordinates. Units of Degrees
. Default +0.0000000
.
Always 8 alphanumeric characters, UPPER CASE
. Default
00000000
TrimTrac ProE Locator Technical Manual v2.0e 154
WGS-84 Coordinates. Units of
. Default +0.0000000
