RESP_METERS
This is the response message to the QUERY_METERS (page 164) message. This
message is also sent whenever either Runtime meter reaches it automatic report
threshold, if so enabled. (See SET_EXT2_APP_CONFIG page 152 for runtime
meter setup instructions).
>RTKABCDDDDDDDDDDEEEEEEEEEE;ID=YYYYYYYY;*ZZ<
A Always 'M': Indicates a query runtime meters message.
B
Runtime Motion-based Reset Confirmation: 0=Report
without Reset; 1=Report with Reset; 2=Disabled
C Runtime LPA-based Reset Confirmation: 0=Report without
Reset; 1=Report with Reset; 2=Disabled
DDDDD
Runtime Motion-based Reading: Accumulated seconds since
DDDDD
last reset, always 10 digits
EEEEE Runtime LPA-based Reading: Accumulated seconds since last
EEEEE
reset, always 10 digits
YYYYYYYY
Unit ID. Always 8 alphanumeric characters, UPPER CASE ONLY
ZZ
Checksum.

Table 83, RESP_METERS Message

RESP_PROV_CONFIG
This is the response message to the SET_PROV_CONFIG (page 158)and
QUERY_CONFIG (page 161) message containing the provisioning information.
>RTKABBBBBBBBBBBBBBBBBBBBBBBB;ID=YYYYYYYY;*ZZ<
A TrimTrac Configuration Set:
Parameters
BBBBBBBB
SMS Destination Address
BBBBBBBB
international dialing "+" sign and country code for SMS messages.
Field padding in SPACES (not 0's) before the
BBBBBBBB
dialing "+" sign
YYYYYYYY
Unit ID. Always 8 alphanumeric characters, UPPER CASE ONLY
ZZ
Checksum.

Table 84, RESP_PROV_CONFIG Message

'V' = Provisioning
.
24 characters including optional
TrimTrac ProE Locator Technical Manual v2.0e 178
international
