Table 75, Resp_Alert_State Message - TrimTrac ProE Locator Technical Manual

deleted. The Message Log can be queried with the QUERY_LOG message from
the server application.
RESP_ALERT_STATE
The TrimTrac ProE sends this message after a SET_ALERT_STATE (page 147)
request is received and processed; provided, however, that the TrimTrac ProE is
connected to a Vehicle Adapter or Control Module. If battery powered, then this
message will not be sent upon receipt of a SET_ALERT_STATE request.
>RTKABCD;ID=YYYYYYYY;*ZZ<
A Always 'L': Indicates operation mode setting
B
HPA Status
4=Monitor Activated
C
MPA
4=Monitor Activated
D
LPA Status
4=Monitor Activated
YYYYYYYY Unit ID. Always 8 alphanumeric characters, UPPER CASE ONLY
ZZ
Checksum.

Table 75, RESP_ALERT_STATE Message

.
0=Normal; 1=Activated; 2=Sent; 3=Acknowledged;
Status.
0=Normal; 1=Activated; 2=Sent; 3=Acknowledged;
.
0=Normal; 1=Activated; 2=Sent; 3=Acknowledged;
TrimTrac ProE Locator Technical Manual v2.0e 169
