Flowserve VTP User Instructions page 71

VERTICAL TURBINE PUMPS (VTPS) CENTRIFUGAL PUMPS ENGLISH 71569224 – 02-15
369 Ring flow
370 Sleeve stuffing box
371 Oring stuffing box sleeve
372 Stud threaded barrel
373 Nut hex barrel
374 Oring barrel
Gasket suction f/adapter
377
column
378 Gasket discharge
Screw cap hex/head
379
discharge
380 Nut hex discharge
381 Screw cap hex/head motor
382 Nut hex motor
383 Cap lubricator tank
384 Band lubricator tank
385 Bolt stove f/tank oiler assy.
386 Nut hex f/tank oiler assy.
Lubrication line f/tank oiler
387
assy.
Fitting compression elbow
388
f/tank oiler assy.
Fitting compression straight
389
f/tank oiler assy.
390 Bearing assembly (ag)
392 Nipple pipe pre-lube
393 Valve gate pre-lube
394 Pin lifting f/head
395 Ring retaining f/head
396 Clip safety f/tube nut
397 Screw cap hex/head tube nut
Adapter column flanged to
399
flanged
Screw cap hex/head adapter
400
column
401 Nut hex adapter column
Bearing rubber cutless
402
discharge case
Adapter column flanged to
403
threaded
405 Oring ingerseal
409 Adapter driver f/m head
412 Stud threaded base plate
413 Nut hex base plate
414 Plug pipe head pre-lube
Plug pipe head inspection
415
hole
416 Plug pipe head pressure tap
Screw cap hex/head coupling
417
guard
Page 71 of 76
2450 Shaft sleeve
4610.# O-ring
6572.# Stud
6581.# Hexagon nut
4610.# O-ring
4590.# Gasket
4590.# Gasket
6570.# Screw
6581.# Hexagon nut
6570.# Screw
6581.# Hexagon nut
6581.# Hexagon nut
3840 Lubrication line
2923.# Pin
6570.# Screw
1140 Discharge casing
6570.# Screw
6581.# Hexagon nut
3300.# Bearing, bushing
1140 Discharge casing
4610.# O-ring
6572.# Stud
6581.# Hexagon nut
6578.# Threaded plug
6578.# Threaded plug
6578.# Threaded plug
6570.# Screw
