Appendix A Technical Information

A.1 Troubleshooting
The following table can help you resolve problems when installing the device. If you cannot resolve them, contact
your dealer for further information.
Symptom
None of the LEDs lights up on
the router.
You have forgotten the router's
access password.
The LAN Switch LED never
lights up in green.
The Eth WAN LED never lights
up in green.
The USB LED never lights up in
green.
A.2 Updating the software
The Teldat Atlas-i70 router can be updated to new versions. Please contact your distributor for further details on
new releases.
There are several ways to update a Teldat router. For further information, please see manual: "Teldat Dm748-I Soft-
ware Updating" .
The software required to update Teldat routers is supplied in a format known as distribution. This consists of a
single file containing all the files needed to update your device, as well as in-depth information on the contents of the
files.
A.3 Connecting to the device
A.3.1 Connecting using the local console (Aux connector)
The Teldat Atlas-i70 router has a RJ45 female connector on the front panel ( Aux.), which provides access to the
device's local console.
Aux Connector
Fig. 30:
To configure this, connect the Aux. port to an asynchronous terminal (or to a PC with terminal emulation).
Teldat Router Atlas-i70
Solution
Check the power supply to the router (power source, ON/OFF switch, main power
outlet).
Ignore the configuration through the RST button (as explained in the relevant sec-
tion).
Check the Ethernet cable and the connection to the network.
Check that the appropriate license is available for use.
Check the Ethernet cable and the connection to the network.
Check that the device inserted in the USB connector is supported by the router.
Please check the Teldat website http://www.teldat.com for a list of supported 3G
USB modems.
Check that the appropriate license is available for use.
