RTCU MX2 turbo Technical Manual V2.04

Power consumption

Detailed information on the maximum power consumption of the MX2 unit in different states and
at different supply voltages is listed below.
Maximum power consumption: Unit running on external supply
Unit Active
Unit Active with GSM On
Unit active with GPS On
Unit Active with GSM/GPS On
Unit Active while charging
Unit in power-down
Unit in "wait for event"
Unit in "wait for event"
Unit in "wait for event"
Unit in "wait for event"
Unit in "wait for event"
Note: Measured at TA = 25 ˚C
If the external power source is removed and the internal battery is enabled the power consumption
from the battery will be as listed below.
Maximum power consumption: Unit running on internal battery
Unit Active
Unit Active with GSM On
Unit active with GPS On
Unit Active with GSM/GPS On
Unit in power-down
Unit in "wait for event"
Unit in "wait for event"
Unit in "wait for event"
Unit in "wait for event"
Unit in "wait for event"
Note: Power consumption from a 80% charged battery at TA = 25 ˚C
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
8V 12V 30V
70 45 20
80 55 22
100 65 26
110 75 30
950 650 300
0.4 0.3 0.2
0.4 0.3 0.2
9 6 3
9 6 3
10 7 4
25 16 7
Battery
100 mA
130 mA GSM idle @ -63dBm
140 mA
180 mA GSM idle @ -63dBm
0.7 mA Restart on DI5, RTC
0.7 mA Resume on DI, Vibration, RTC
12 mA Resume on CAN
12 mA Resume on RS232 port 1
13 mA Resume on RS232 port 2
35 mA Resume on GSM activity
Page 28 of 36
mA
mA GSM idle @ -63dBm
mA
mA GSM idle @ -63dBm
mA
mA Restart on DI5, RTC
mA Resume on DI, Vibration, RTC
mA Resume on CAN
mA Resume on RS232 port 1
mA Resume on RS232 port 2
mA Resume on GSM activity
