RTCU MX2 turbo Technical Manual V2.04

System LED S1 and S2

The RTCU is equipped with two system LED's which shows the status and possible errors of the
RTCU unit.
The different patterns are listed in the table below. If the color of the system LED S1 is yellow, the
unit is actively communicating with the RTCU IDE (or another program, supporting the RTCU
RACP protocol).
The single yellow LED is signaling either the GSM module activity, or if all other LED's are off,
that the RTCU is in the "wait for event" low power state.
S1: System LED1 pattern overview
Pattern
Fastest blinking, green
Fast blinking, green
1
500ms On / 500ms Off green
1.5s On / 0.5s Off. green
Fast blinking, red 1
Alternating Fast/Slow, red
75ms On / 925ms Off, green
S2: System LED2 pattern overview (GSM activity and "Wait For Event")
Pattern
Off
600 ms On / 600 ms Off
75 ms On / 3 s Off
75 ms On / 75 ms Off /
75 ms On / 3 s OFF
Flashing
On
8 s OFF / 10 ms ON
(and all other LED's OFF)
1 Or yellow when communicating with the RTCU IDE or another program, supporting the RTCU RACP protocol).
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Description
The unit is initializing, preparing to start the application.
The unit has been forced into recovery mode with the use of
the system switch. The application is not executing.
1 The unit is executing the application program
The unit is executing the application program, while
1
charging the internal back-up battery.
A runtime error has been detected in the program.
Use the RTCU IDE to obtain the fault log.
The unit has lost its firmware! This can only happen if,
1
during a firmware upgrade, the RTCU unit loses power or
the communication is lost completely. In this case, simply
upload the firmware to the unit again.
Execution speed is different from full-speed.
Operating Status
The GSM module is turned off
Missing SIM card or PIN code.
Network search and logon in progress.
Logged on to the network.
A 3G/GPRS session is active.
Indicates 3G/GPRS data transfer.
A voice or CSD session is active.
The RTCU unit is in low-power "Wait For Event" state.
