RTCU MX2 turbo Technical Manual V2.04

Installing the internal SIM-card

The internal SIM-card reader is located internally on the top-side of the base-board. The reader
does not have a mechanical detection, or lock status pins.
If the SIM-card is removed during GSM operation the unit will shortly after be rejected from the
GSM network.
Please refer to Appendix B for detailed description of installing the internal SIM-card.

SD-CARD reader

The RTCU MX2 turbo unit has a standard SD-CARD reader with a FAT32 file-system support for
standard PC-compatibility, with up to 32 GB capacity support.
The SD-CARD reader features a Push/Push eject system for reliable insertion and operation.

Approved SD-CARDs

To ensure the highest performance and compatibility it is important to use SD-CARDs that has
been approved and tested by Logic IO.
The following Commercial Grade SD-CARDs from Sandisk have been approved for use:
Capacity
4GB
8GB
16GB
32GB
Commercial grade SD-CARDs can be used in applications where the limited write endurance is
acceptable - for example if the SD-CARD is often replaced. Commercial grade SD-CARDs should
not be used in applications where a potential failure on the media is considered mission critical.
For applications that uses the SD-CARD media extensively and where a failure is critical, it is
recommended to use approved Industrial Grade SD-CARDs.
Logic IO has approved and recommends industrial grade SD-CARDs from ATP that is available in
capacities from 512 MB to 32 GB.
ATP Industrial Grade SD/SDHC Cards are optimized for demanding industrial applications with
consistent performance in all conditions. ATP uses reliable SLC flash technology with a flash
endurance more than 20 times higher than commercial grade products with MLC flash.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Sandisk SKU
SDSDB-004G-B35
SDSDB-008G-B35
SDSDB-016G-B35
SDSDB-032G-B35
Page 25 of 36
