RTCU MX2 turbo Technical Manual V2.04
Connector X4: 6 pin SER1 connector overview
Pin Name
1 TD
2 RS-DET
3 DC-Out
4 RD
5 SGND
6 SGND
Connector SER2: RJ45 connector overview, fully RS232 compatible
Pin Name
1 DSR
2 DCD
3 DTR
4 SGND
5 RD
6 TD
7 CTS
8 RTS

Accessories for cable assembly

Order-code
RT-O-TYCO-H4
TYCO p/n: 794617-4
RT-O-TYCO-H6
TYCO p/n: 794617-6
RT-O-TYCO-H12
TYCO p/n: 1-794617-2
RT-O-TYCO-H16
TYCO p/n: 1-794617-6
RT-O-TYCO-CR
TYCO p/n: 794606-1
RT-O-TYCO-TOOL
TYCO p/n: 91501-1
Recommended tool:
Alternative tools:
Extraction tool:
2.5mm MicroJack
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Description
Transmit Data from serial port 1, RS232 compatible
Programming cable detect, normally unconnected
(if programming cable, connect to GND)
+3.3V/150mA DC-Out for external equipment.
(Shared with X2)
Receive Data for serial port 1, RS232 compatible
Signal Ground
Signal Ground
Description
Data Set Ready
Data Carrier Detect
Data Terminal Ready
Signal Ground
Receive Data for serial port 2
Transmit Data from serial port 2
Clear To Send
Request To Send
Name
Tyco, Connector house 4 pins. Bag with 10 pcs
Tyco, Connector house 6 pins. Bag with 10 pcs
Tyco, Connector house 12 pins. Bag with 10 pcs
Tyco, Connector house 16 pins. Bag with 10 pcs
Tyco, Crimp Contacts for connector house. Wire size 0.2 to 0.5 mm
Bag with 100 pcs.
Tyco, Crimp hand tool for easy assembly of TYCO crimp contacts.
Wire size 0.2 to 0.5 mm
Tyco 91501-1 (0.20 to 0.50mm
Tyco 91502-1 (0.05 to 0.15mm
Tyco 843996-6 extraction tool. RS 495-9704, Farnell 1111477
Plug for headset connector. Farnell 5096339 (black plastic house) or
Farnell 8045453 (metal house).
Page 9 of 36
2
2 ) RS 495-9675, Farnell 1111475
) RS 495-9675, Farnell 1111476
2
2 .
