Digital Outputs
The digital outputs control eight "high-side" switches. They function like a contact, where one side
is connected to the positive supply of the RTCU unit and the other is the output. The switches are
protected against short circuit, ESD and electronic kickback from inductive loads such as relays etc.
The maximum switchable inductance is 20mH and must not be exceeded.
The digital outputs are supplied through the X1 power connector that also supplies the rest of the
RTCU unit. As the power is also the RTCU MX2 turbo main power, a power-fail would also affect
the digital outputs.
The RTCU unit offers very advanced power management which makes it possible to have one or
more outputs enabled while the RTCU is in low-power mode. Please consult the RTCU IDE on-line
help for more information.
X3: 16 pin I/O connector overview
Pin
Name
1
DOUT 1
9
DOUT 2
2
DOUT 3
10
DOUT 4
Specification for each digital output
Type
Max.
36
Solid state
1.5
Please note: Special attention to wiring must be taken; if the total current consumption of the
digital outputs exceeds 1.5A, then PGND must be used as return path for the output(s).
If the total current consumption of the digital outputs exceeds 5A, the two SUPP pins must be used
for supply.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Description
Digital output 1
Digital output 2
Digital output 3
Digital output 4
Unit
VDC
Short-circuit, ESD,
A
Inductive kick-back protected up to 20mH.
