Power consumption

The table below shows detailed information about the typical power consumption for the RTCU
NX-900 device while it is running.
DC power consumption: Device operating in normal mode
Device active
Device active with Cellular on*
Device active with GPRS session*
Device active with GNSS on
Device active with WLAN on
Device active with Ethernet on
Device active with RF sending.
Device active while charging
Note: Values marked with (*) is average and should be considered as guidelines as they may vary
depending on the cellular signal strength.
Note: Power consumption from a fully charged battery.
AC power consumption: Device operating in normal mode
Device active
Device active with Cellular on*
Device active with GPRS session*
Device active with GNSS on
Device active with WLAN on
Device active with Ethernet on
Device active with RF sending.
Device active while charging
Note: Values marked with (*) is average and should be considered as guidelines as they may vary
depending on the cellular signal strength.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
12V 24V BAT
70 35 180
110 55 300
300 120 800
100 55 280
100 55 300
100 45 310
75 40 190
620 310 -
220V AC
1
2.5
4
2.5
1.5
1.5
3.5
9
Page 41 of 50
mA
mA idle @ -63dBm* (2G)
mA @ -65dBm, Battery not
charging*
mA Mode 3
mA Connected to AP, in idle
mA Connected to switch, in idle
mA
mA
W
W idle @ -63dBm* (2G)
W @ -65dBm, Battery not
charging*
W Mode 3
W Connected to AP, in idle
W Connected to switch, in idle
W
W
