RTCU MX2 turbo Technical Manual V2.04
The differences in write endurance between commercial grade MLC flash and ATP Industrial
grade SLC flash is quite remarkable for write-intensive applications:
Product Line
ATP Industrial Industrial SLC Flash
Grade + Advanced Wear Leveling
Grade A MLC
Commercial
(2 bits per cell)
Grade
+ Advanced Wear Leveling

Installing the SD-CARD

To insert a card into the reader, orientate it as shown below and push the card into the reader until
a click sound occurs. Remove the card by pushing it into the reader until it clicks and the reader
will eject the card. Avoid removing the SD-CARD during access to the card.
Please consult the RTCU IDE documentation for more information.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Total Writeable Data
Details
Page 26 of 36
Prediction @ 1GB
80,000GB
or
2,800,000 writes
4,000GB
or
140,000 writes
SD-CARD orientation
Time Prediction
@ 500 writes a day (1GB)
5,740 days
or
15.7 years
280 days
