Connector X1: 4 pin PWR connector overview
Pin Name
1 SUPP
2 DI5/IGN
3 SUPP
4 PGND
Connector X2: 12 pin COM connector overview
Pin Name
1 1Wire
2 SGND
3 CAN-H
4 Voice
5 RS485+
6 RS485-
7 1W-LED
8 SGND
9 CAN-L
10 SGND
11 SGND
12 DC-Out
Connector X3: 16 pin I/O connector overview
Pin Name
1 DOUT 1
2 DOUT 3
3 DIN 1
4 SGND
5 DIN 3
6 DIN 5/IGN
7 AIN 1
8 AIN 2
9 DOUT 2
10 DOUT 4
11 DIN 2
12 SGND
13 DIN 4
14 SGND
15 AGND
16 AGND
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Description
Power supply, positive (+) connection
Digital input 5 / Ignition input (Shared with X3)
Power supply, positive (+) connection
Power Ground
Description
1-Wire bus
Signal Ground
CAN-bus H-signal
External voice
RS485 non-inverting signal
RS485 inverting signal
1-Wire ID-Button LED
Signal Ground
CAN-bus L-signal
Signal Ground
Signal Ground
+3.3V/150mA DC-Out for external equipment. (Shared with X4)
Description
Digital output 1
Digital output 3
Digital input 1
Signal Ground
Digital input 3
Digital input 5 / Ignition input (Shared with X1)
Analog input 1
Analog input 2
Digital output 2
Digital output 4
Digital input 2
Signal Ground
Digital input 4
Signal Ground
Analog Ground
Analog Ground
