External connections

Overview

Connections to external equipment are done via the connectors located on the back and front of the
RTCU MX2 turbo.
The front panel is equipped with connectors commonly accessed by the user: SIM-Card, SD-
CARD, DIP-Switch, Headset, LED's and RS232.
The back panel holds all connectors necessary for installation: 4-pin (X1) power and ignition, 6-pin
(X4) for RS232/Programming, 12-pin (X2) for different communication interfaces and a 16-pin (X3)
for analog and digital I/O. Connection to the GSM antenna is via a SMA female, and connection to
a 3V active GNSS antenna is done via the SMB male connector. Both antenna connectors are
located on the back panel.
A graphical overview of the front- and back are shown below:
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Hands-free
Sim Card Reader
Connector
SD-CARD Reader
Dipswitch
Front-side view
GSM
GNSS
antenna
antenna
1
1
4
7
X4: SER1
X2: COM
Back-side view
Page 7 of 36
Pin 1
A S1
B
S2
SER2
System Switch
1
X3: I/O
9
1
1
3
X1: PWR
