EVAL-ADuM5028EBZ

ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Reference Designator Description
U2 ADuM5028
U1 ADP7104
semiconductor (CMOS) LDO
C1, C2, C5, C6, C8 Capacitors, X7R, 10 μF, 0805
C3, C4, C7 Capacitors, X7R, 0.1 μF, 0603
E1, E4, E5 Ferrite beads, 1500 Ω, 0603
E2, E3 Ferrite beads, 1.8 kΩ at 100 MHz, 0402
JP1 100 mil (2.54 mm) connector PCB header
Not applicable 100 mil (2.54 mm) jumper
P1 Connector, PCB, terminal block, 5.0 mm pitch, 16-26 AWG
P3, P6 Connectors, PCB, terminal blocks, horizontal cable entry, 5 mm
pitch
R10 Resistor, 22.1 kΩ, 0603
R8, R11 Resistors, 13.0 kΩ, 0603
R13 Resistor, 100 kΩ, 0603
R3 Resistor, 0 kΩ, 0603
R9 Resistor, 18.2 kΩ, 0603
TP1 to TP6 Connector PCB test points
P2, P5 Connector PCB headers, 2.54 mm, 3 position vertical (not
installed)
R12 Resistor, 0 Ω, 0603 (not installed)
R2 Resistor, 0 Ω, 0603 (not installed)
R1, R4 to R7, R14 Resistors, 300 Ω, 0805 (not installed)

RELATED LINKS

Resource Description
ADuM5028 Low Emission, Isolated, DC-to-DC Converter
AN-1349 PCB Implementation Guidelines to Minimize Radiated Emissions on the
AN-0971
Recommendations for Control of Radiated Emissions with isoPower® Devices
User Guide
low emission isolated, dc-to-dc converter
20 V, 500 mA, low noise, complimentary metal oxide
Rev. A | Page 7 of 8
Supplier
Analog Devices
Analog Devices
Wurth Elektronik
Wurth Elektronik
Murata
Taiyo Yuden
Wurth Elektronik
FCI
Wurth Elektronik
Wurth Elektronik
Panasonic
Panasonic
Panasonic
Vishay
Panasonic
Vero Technology
MOLEX
Panasonic
Vishay
Panasonic
ADM2582E/ADM2587E RS-485/RS-422 Transceivers
UG-1263
Part No.
ADuM5028-5BRIZ
ADP7104ACPZ
885012207026
885012206046
BLM18HE152SN1D
BKH1005LM182-T
61300421121
65474-001LF
691213710003
691 213 710 002
ERJ-3EKF2212V
ERJ-3EKF1302V
ERJ-3EKF1003V
CRCW06030000Z0EA
ERJ-3EKF1822V
20-2137
22-03-2031
ERJ-3GEY0R00V
CRCW06030000Z0EA
ERJ-6ENF3000V
