Planning the Turbo Fan Installation
Carefully plan the installation. Dimensions are provided for the Turbo Fans with Cones and the Turbo Fan Covers.
See Figure 1. Be sure to allow enough space to install fans without interfering with other fans or equipment.
14" Turbo
Fan (52.07 cm)
18" Turbo
Fan (63.50 cm)
24" Turbo
Fan (80.01 cm)
MV1517-2 3/98
Figure 1. Fan Dimensions
A Sq. B
20.50" 38.25" 17.75"
(97.16 cm) (45.09 cm)
25.00" 38.50" 17.50"
(97.79 cm) (44.45 cm)
31.50" 40.00" 19.75"
(101.6 cm) (50.17 cm)
C D Dia. E
24.75" 4.50"
(62.87 cm) (11.43 cm)
28.75" 4.50"
(73.03 cm) (11.43 cm)
35.3" 4.50"
(89.66 cm) (11.43 cm)
14, 18, and 24 Fiberglass Turbo
F G
21.50" 22.25"
(54.61 cm) (56.52 cm)
28.00" 26.25"
(71.12 cm) (66.68 cm)
34.75" 33.50"
(88.27 cm) (85.09 cm)
®
Fans
H
22.00"
(55.88 cm)
29.00"
(73.66 cm)
34.75"
(88.27 cm)
7
