Chore-Time Turbo Installation & Operator's Instruction Manual page 11

Installing the Weather Cover and Cover Guard
The Plastic Hood should be installed over the fan as shown in Figure 5.
The Hardware Kit includes 2" screws or 2-1/2" nails and 1" outside diameter washers to secure the Hood to the
building.
Install the Guard Cover on the Weather Cover opening, using the 1/4-20 x 7/8 plastic bolts, 5/8 outside diameter flat
washers, and 1/4-20 plastic nuts supplied. See Figure 5.
MV1517-5 2/98
Item Description
1
Turbo
2 Weather Cover
3 Cover Guard
Figure 5. Installing the Weather Cover and Cover Guard
14, 18, and 24 Fiberglass Turbo
1
2
3
®
Fan
®
Fans
11
