Parts Listing: 48" BD Shutter Fan

Item Qty. Description
1* 1 Motor
2 38 Bolt, Carriage 5/16-18 x .625
3 38 5/16-18 Hex Ser. Flange Nut
4 4 48" Shutter Fan Panel
5 1 Shroud 48'' Fan
6 2 48" Fan Post
7 1 Motor Mount Pivot Plate
8 1 Pivot Plate Mounting Bracket
9 1 Z-Motor Mounting Bracket
10 1 ST BD Module Bushing
11 1 Spring
12 1 48" Fan Blade
13 1 5-16-18 x 3/8 Set Screw
14 2 1/4 x 1 x 1/8 Square Key
15 1 Shaft
16 1 Rear Bearing Mount Plate
Part
Item Qty.
Number
Varies 17 1 Front Bearing Mount Plate
8282 18 2 1" Bore Cast Flange Bearing
8490 19 1 8-1/4" O.D 1" Bore Sheave
45719 20 1 AX56 V-Belt 58.2
37583 21 2 Danger Decal
43688 22 1 EZ Fan Decal
43713 23 16 Screen Clip
46444 24 1 48" Wire Screen
46445 25 1 5/16-18 x 5.5" Bolt
38896 26 2 Spring Coil Cap
43715 27 3 .375 x .875 x .078 Flat Washer
28140 28 4 5/16-18 x 1.25 Carriage Bolt
1174 29 3 5/16-18 Hex Lock Nut
2419-2 30* 1 Cast Iron Sheave
43691 31 1 48" Fan Shutter Rail
43690 32 32 48" Shutter Louver
33 16 48" Shutter Rod
*See Shutter Fan Specifications Page 20.
Part
Description
Number
43689
43654
42072
43816
2527-50
39002-131
38891
45865
4412-21
44002
546
34885-2
2148
Varies
40510
38038-12
38702-11
